管道工厂预制详图转化软件

功能介绍 Function introduction

产品型号:SmartPlantSpoolgen

Model: SmartPlantSpoolgen

最新版本:2014R1

Latest Version: 2014R1

性能特点:Intergraph鹰图软件产品;具有English、中文两种语言(自由切换);自身独有软件运行平台;可方便地导入IDF(ISOGEN Data File,来自Intergraph PDS and AVEVA PDMS )、PCF(Piping Component File ,来自Intergraph SmartPlant 3D and CADWorx),实现与设计院/工程公司的无缝数据对接,生成3D单线图模型。设置现场口位置后,可生成安装所需的单线图和管道预制所需的管段图,并可导出管线、管段、焊缝、材料、长度等信息

Performance Feature: Intergraph Corporation producing; with English and Chinese two languages available (free to switch); it's own unique software operating platform; can easily to import IDF(ISOGEN Data File which comes from Intergraph PDS and AVEVA PDMS ) and PCF(Piping Component File which comes from Intergraph SmartPlant 3D and CADWorx),realizes seamless data docking with Design Institute / engineering company and generates 3D ISOMetric Drawing model. After the fieldweld joints position being confirmed, it can generates the ISOMetric drawing required for installation and the piping spool drawing required for prefabrication, and also export the information of the piping line, piping spool, weld joint, requested materials and length etc.
