产品型号：DPCBM-16Aa/24Aa
Model: DPCBM-16Aa/24Aa
适用管径：DN400/DN600
性能特点：前后两组液压缸驱动的凸轮夹紧机构同步对中夹紧管子；切断坡口刀盘绕管中心高速旋转，当2个伺服电机分别驱动的内外2个大盘产生速度差时，进刀齿轮传动机构开始动作，驱动切断坡口刀自动径向进刀；配备喷雾冷却装置；触摸屏人机界面坡口参数预置，PLC控制；四根立柱、四根线性导轨和2台升降机组成的升降系统实现自动机械调心；管子切断坡口一次成型（两道坡口）、坡口工作效率极高；适用于大批量普通壁厚（≤25mm）管子的坡口加工
Performance Features: synchronously centering clamping with drive by the front and back two groups of hydraulic cylinders cam mechanism; cutting and beveling blade disc rotatesat high speed around the pipe center; when generate speed difference from 2 cutter disc of internal and external are respectively drive by 2 servo motors, the cutting feed gear drive mechanism began to motion, to drive cutting tools and beveling tools automatic radial cutting feed; its equipped with spray cooling device; cutting and beveling blade automatically feed in opposite direction; Preset bevel parameters throughPLC touch screen human-machine interface ; Four-column& four linear guide rail & two lifts to compose lifting systemenabling automatically mechanical centering; cuttingand beveling in one operation ( simultaneously producing two bevels); extremely high beveling efficiency; applicable for large amount of STD wall thickness （≤25mm）pipe bevel machining.
