整体式管道自动焊机（厚壁型）

产品型号：PFAWM-24Ae/32Ae/48Ae/64Ae

Model: PFAWM-24Ae/32Ae/48Ae/64Ae

适用管径： DN600/DN800/DN1200/DN1600

Pipe Diameter Applicable: DN600/DN800/DN1200/DN1600

性能特点：墩实款式；适用于大批量厚壁管道预制场合；2组4个包胶驱动滚轮；电机减速机驱动；2组4个包胶压紧滚轮；外置丝杆升降机构压紧；驱动滚轮及驱动系统内置；纵向伸缩臂快速焊口定位；标配林肯Flextech650多功能焊接电源；采用QSPT打底焊接技术，进行TIG/MIG打底焊接；TIG/MIG/MAG/SAW填充、盖面焊接；流线型焊接控制箱+铝合金线控盒操作；是厚壁管道焊接的设备。

Performance Features: The sturdy model for welding heavy wall thickness pipes; suitable for large batch of heavy wall thickness pipe fabrication; twosets of polyurethane coated driving wheels(two pcs per set, totally four pcs); driven by motor and reducer; twosets of polyurethane coated hold-down wheels(two pcs per set, totally four pcs); held-down by embedded screw rod mechanism; built-in drivingwheel and exposed driving system;fast positioning weld with longitudinal telescope boom;standard configuration: Lincoln Flextech650 multi-function welding power; TIG/MIG root welding with QSPT’s root welding technology; TIG/MIG/SAW fill-in and cap welding;operation with a streamline welding control cabinet + an aluminum alloy wire control box.
